Place of Origin:
Shanghai, China
Brand Name:
Tianfeng
Certification:
CE/ISO
Model Number:
SZS230
Uphill tablet deduster for tablet/pill polishing machine dust removed machine SZS230
Main purpose
SZS200 / SZS230 model machine is an economical top rotation type tablet sieving machine. It has three functions such as tablet grinding, dust removing and lifting. The machine inlet can be connected with any model of tablet press and the outlet can be connected with metal detectors. It can realize the linked production mode
of tablet grinding, dust removing, lifting and metal foreign matters detection.
Main feature
1.The machine has features of long tablet dust removing path, automatic tablet face turning and grinding, and good dust removing effect.
2.The parts in the machine that contact the med cine are made of SUS304, meeting GMP requirements.
3.The screen and outer cover of the machine adopt a building block type design. The outlet height is easy to adjust.
4.The machine adopts a quick installed connection structure, making it more convenient to disassemble and install the machine. There is no dead corner for cleaning.
5.The machine inlet and outlet can be subject to 360° adjustment to facilitate production ans save space.
Technical Parameter:
| Model | SZS200 ~ 230 |
| Max. Outoutput | 800,000 tablets per hr. (based on ø6mm tablets, wt. of 12z0mg) |
| Rated powder | 110V, 60Hz, 1Ph, 150W (0.2HP) or 220V/50Hz |
| Dedusting Distance | 6.0 m (20.3 ft) |
| Maximum Tablet Diameter | ø3mm-ø25mm |
| Compressed Air | 0.1 m3/min (35CFM)- 0.1MPa (15 psi) |
| Max lifting height | 1220mm |
| Vacuum | 2.7 m3/min (880CFM) - 0.1MPa (15 psi) |
| Noise Level | <75 db |
| Dimension(L*W*H) | 500mm x 550mm x 1350mm ~1500mm |
| Weight | 70Kg (155 lbs) |
Export standard plywood package are supplied with well packed. We can make the packages according to customer's request. Sea packages or Air packages are both available.
Usually shipped solid preparation auxiliary equipment stainless steel tablet deduster SZS230 by sea with tablet press
One station service to make sure our customer get good products and good service.
(1) Professional advice and rich experience help to choose machine.
(2) Warranty time: All machines are guaranteed for one year.
(3) Any problem: If you have any questions or any demands, we will reply you within 24 hours
except the special reasons once you enquiry us.
(4) Additives: installation book, Manual book, tool box will be sent with machine.
Product Quality
All products are guaranteed for one year, if any problems happen in guarantee period, our company will maintain for free.
Technical Service
We can provide design, installation and debugging services or remote maintenance teaching.
Delivery The Cargo To Nearest Port
We will arrange the shipment and delivery the cargo to your nearest port, save time and cost.
Detail Product Information
Provide picture, video, instruction and product brochure.
Reply Timely
24 hours hot line ,we will reply email within 12 hours.
1. What about your machine quality?
Our factory has more than 30 years experience in mechanical processing; all our machines already get ISO9001, SGS certificate, CE certificate; already exported to many countries and areas; already got customer’s good reputation.
2. What about your machine price?
Anytime we will garanteen quality first, no matter price is good or not for us. Quality is first, on the top quality basis, of coursse you will get reasonable and satisfied price!
3. How can you ensure the machines' quality after we put the order?
Before the delivery, we will send you machines' pictures and videos, or you can come to our factory to make the quality checking by yourself, or by the third party inspection organization that contacted by your side.
